Advantages:
- Quick and easy to handle
- Robust plastic jacket for long life
- Easy to lay thanks to “memory effect”
Application:
- Internal wiring of racks, audio and hifi components
Technical Data:
- Name: SC-Isopod SO-F22
- Properties: OFC oxygen free copper
- Properties: Analog
- Application area: Installation
- Application: Patch cable
- Colour: blue
- Signal transmission: symmetrical
- Construction: (2LI2Y0,22mm²)(ST)Y
- Jacket material: PVC
- Jacket Ø: 3,30 mm
- Number of Channels (audio): 1
- Inner conductor (audio): 2
- Inner conductor (audio): 0,22 mm²
- Inner conductor Ø (audio): 0,53 mm
- AWG (audio): 24
- Shielding: AL / PT foil + AL / PT foil + filler strand, tin-plated
- Shielding factor: 100 %
- Copper strands (audio): 7
- Copper strand Ø (audio): 0,20 mm
- Conductor insulation material: PE
- Conductor insulation Ø: 1,12 mm
- Conductor insulation Ø: 0.0441 "
- Weight per 1 m: 16 g
- Weight at 1000 ft.: 10.7667 lbs
- Fire load per m: 0,05 kWh
- Style variant: round
- Packing: 200 m spool
- Temperature min.: -25 °C
- Temperature max.: 70 °C
- Width: 3,3 mm
- Height: 3,3 mm
- Capac. cond./cond. per 1 m (audio): 74 pF
- Capac. cond./shield. per 1 m (audio): 143 pF
- Insulation resist. per 1 km: 0,2 GΩ
- Insulation resist. per 1 km (audio): 0,2 GΩ
- Conductor resistance per 1 km: 88 Ω
- Shield. resistance per 1 km: 75 Ω
- BPVo-Euroclass: Fca
on stock delivery within 2-3 days
